Plumbing and drainage layouts — building on a 22×57 plot
Plumbing · 22x57 ft · G+1
Design code DS1144 — quote it when you call or message us.
Design fee
Price on request
From our rate card
- ₹1,999 · Electrical and plumbing drawings · Both layouts for one home · built-up area up to 1,250 sq ft
- Design type
- Construction Drawings
- Design code
- DS1144
- Drawing type
- Plumbing
- Plot size
- 22 × 57 ft
- Plot area
- 1,254 sq ft (139 gaj)
- Floors
- Two floors (G+1)
About this design
Plumbing plans for a building with ten attached toilets: fixtures, drain lines in red, inspection chambers and the septic tank with its inlet and outlet.
- Drain lines
- Inspection chambers
- Septic tank
- Ten attached toilets
Questions about this design
Can you prepare these drawings for my house?
Yes. Send us your floor plan, or ask us to make one, and we prepare the same set of drawings for your plot. The sheets shown here are from one of our projects and show what you receive.
What happens after I send a request?
A designer calls you within one working day to understand your needs, then shares a quote and timeline.
